Parts Engine Motores e Peças:

MOTORES BMW N52 N53 N54 N55 VEIUCLOS BMW 125 128 130 135 Z1 Z4 X3 X4 X5 535 540 TODOS COMOTORS N52 N53 N554 N55

BEARING WIDTH 1 19.85 MM 18.85 MM 18.85 MM 23.95 MM
WALL THICKNESS 2.508 MM 2.508 MM 2.508 MM 2.508 MM
MIN. SHAFT DIAMETER 64.961 MM 55.961 MM 55.961 MM 55.961 MM
MAX. SHAFT DIAMETER 64.980 MM 55.980 MM 55.980 MM 55.980 MM
MIN. HOUSING BORE 70.000 MM 61.000 MM 61.000 MM 61.000 MM
MAX. HOUSING BORE 70.019 MM 61.019 MM 61.019 MM 61.019 MM
DISTANCE CRANK WEB FROM 24.020 MM
DISTANCE CRANK WEB TO 24.053 MM
AXIAL PLAY FROM 0.100 MM
AXIAL PLAY TO 0.244 MM

Marca/Fabricante: Ks
